P/N: 101-016x

The Link MAP sensors options available go from 1.15 up to 4 Bar of absolute pressure. This means that they are suitable for aspirated and turbo or supercharged applications running up to 3.0 Bar (or 44psi) of boost. The wiring pinout for this sensor is marked directly on the sensor.

Sensor Kit Includes:

• 3-pin Deutsch DTM connector kit

• Easy to mount via 2 bolt holes. Note that the sensor should be mounted higher than the intake manifold port that the hose connects to.

• Compact aluminium enclosure

• Mechanical connection via 4mm (3/16″) hose connector nipple.

• Using Link G4/G4+/G4X ECU’s just select the MAP sensor type in PC Link as ‘Link 4 Bar’.
